ART 1500GV ArmLift is a CE EN 1570-1 certified lift-and-tilt table designed for ergonomic load positioning in industrial production environments, handling up to 1500 kg. The 1000×1300 mm work surface delivers a 550 mm lift stroke from a minimum height of 380 mm, with a 16-second cycle time controlled via a standard 4-button panel and an internal hydraulic power pack (400V three-phase, 0.95 kW S3). Long-side tilt range of +5°/-40° is supported by an integrated load restraint (H=230 mm) to secure the load throughout the tilt cycle.

The ART 1500 ArmLift is a CE - EN 1570-1 certified lift-and-tilt table designed for ergonomic load positioning in industrial environments. It handles loads up to 1500 kg with a 550 mm lift stroke (minimum height 235 mm) and a 1000 × 1300 mm work surface. The tilt function operates on the long side across a +5° to -40° range, combined with a load restraint system (H=230 mm); the lift cycle completes in 16 seconds via an external power pack (0.95 kW S3, three-phase 400V supply) controlled by a standard 4-button unit.

The ART 750 ArmLift is a lift-and-tilt table designed for assembly workstations and internal logistics, with a load capacity of 750 kg and a lift stroke of 550 mm (minimum height 235 mm). The 1000×1300 mm platform tilts on the long side with a range of +5°/-40°, supporting ergonomic operation during picking or assembly tasks. The external hydraulic power pack (3 m cable, 0.95 kW S3 duty, 400 V three-phase supply) and load restraint H=230 complete the standard 4-button configuration. CE certified to EN 1570-1.

ALT 1500 ArmLift is a lift-and-tilt table designed for industrial applications with a load capacity of up to 1,500 kg. The 820 mm lift stroke, 235 mm minimum height, and 1,300 × 800 mm work surface make it suitable for ergonomic feeding of assembly lines and workstations. Tilt operates on the short side with a range of +5° to -40°, controlled via a 4-button external control unit powered by three-phase 400V supply at 0.95 kW (S3). CE certified to EN 1570-1.

ALT 750 ArmLift is a lift-and-tilt table with a 750 kg load capacity, 820 mm lift stroke, and 1300×800 mm work surface, designed for assembly and industrial logistics workstations requiring ergonomic height and angle adjustment of the load. Tilting on the short side reaches -40°/+5°, with an integrated load restraint H=230 mm ensuring load stability throughout the cycle. The internal 0.95 kW (S3) motor unit, powered by three-phase 400V supply, completes a full lift cycle in 18 seconds via a standard 4-button control unit. The product is CE certified in accordance with EN 1570-1.

The TCB 600H is a low-profile scissor lift table rated at 600 kg, with a minimum platform height of 85 mm and a lift stroke of 965 mm on a 1500×900 mm deck — suited for ergonomic workstations or flush-floor integration in production lines. The electro-hydraulic drive (0.95 kW, three-phase 400 V) raises the platform in 19 seconds via an external power pack with plastic cover (cable L=3 m) and a standard 2-button control unit. CE certified to EN 1570-1, total weight 180 kg.

The TCB 600 is a low-profile scissor lift table (minimum height 85 mm) with a 600 kg load capacity and a 715 mm lift stroke, designed for integration into production lines where vertical clearance is restricted. The 1500 × 900 mm platform reaches working height in 13 seconds, driven by a 0.95 kW (S3) three-phase 400V motor unit with a 3 m external power pack. Operation is managed via a standard 2-button control unit; the unit is CE certified in accordance with EN 1570-1.

The TCL 2000GB is a low-profile scissor lift table with a 2000 kg load capacity, a minimum platform height of 100 mm, and a lift stroke of 820 mm, designed for integration into production lines where minimal closed height is a key layout constraint. The 1350 × 1270 mm deck provides a wide working surface for the ergonomic handling of bulky loads, with a full lift cycle completed in 24 seconds. Equipped with an external power pack (0.95 kW S3, three-phase 400 V) and a standard 2-button control unit, it allows straightforward integration into existing industrial environments. CE certified to EN 1570-1.

The TCL 2000B is a low-profile scissor lift table with a 2000 kg load capacity, a minimum platform height of 100 mm and an 820 mm lift stroke, designed for flush-floor integration in production and logistics environments. The 1350 × 1000 mm platform reaches the working height in 24 seconds via a 0.95 kW (S3) three-phase 400V motor unit with a 3 m external power pack. Operation is managed by a standard 2-button control unit, suitable for ergonomic workstations and assembly lines. CE certified to EN 1570-1.

The TCL 2000 is a low-profile scissor lift table rated at 2,000 kg capacity, with a minimum platform height of 100 mm and an 820 mm lift stroke, designed for integration into production lines and ergonomic workstations where floor-level loading is required. The 1,350 × 800 mm platform reaches working height in 24 seconds via an external power pack (0.95 kW S3, 400V three-phase supply) operated by a standard 2-button control unit. CE certified to EN 1570-1, it is suited for heavy-duty industrial material handling applications with verified regulatory compliance.

The TCL 1000GB is a low-profile scissor lift table with a 1000 kg capacity, 80 mm minimum height and 820 mm lift stroke, designed for integration in production environments where floor space below the load platform is limited. The 1350×1270 mm platform and 13-second lift time make it suitable for ergonomic workstations and heavy-load handling on assembly lines. The three-phase 400V power supply with external power pack (L=3m) and 2-button control unit ensure straightforward installation and immediate operation. CE certified to EN 1570-1.

The TCL 1000B is a low-profile scissor lift table rated at 1000 kg capacity, with a minimum platform height of 80 mm and a lift stroke of 820 mm, designed for flush-to-floor integration in production lines and material handling stations. The 1350×1000 mm platform reaches working height in 13 seconds via a 0.95 kW (S3) three-phase 400V motor unit, with a 3 m external power pack and a standard 2-button control unit. CE certified to EN 1570-1 and weighing 180 kg, it suits ergonomic workstations, AGV interfaces, and loading/unloading applications where entry height is a critical constraint.

The TCL 1000 is a low-profile scissor lift table with a minimum height of 80 mm, designed for industrial environments where under-platform clearance is restricted. It handles loads up to 1,000 kg with an 820 mm lift stroke and a 1,350 × 800 mm platform, making it suitable for a wide range of material handling and ergonomic workstation applications. The lifting cycle completes in 13 seconds via an external 0.95 kW (S3) power pack running on 400V three-phase supply, operated by a standard 2-button control unit. CE certified to EN 1570-1.

The TCR 500 is a low-profile scissor lift table with a minimum platform height of 80 mm, designed for integration into production lines and ergonomic workstations where vertical clearance is restricted. A 500 kg capacity, 630 mm lift stroke, and 9-second rise time deliver efficient cycling in medium-duty industrial environments. The unit runs on triphase 400V with an external power pack (cable L=3m) and 2-button control; the 900×600 mm platform is CE certified to EN 1570-1.

The CCB 1000XB is a low-profile scissor lift table with a 1000 kg load capacity and a 1500×1200 mm platform surface, designed for installations where a minimum height of 85 mm is a critical constraint. The 715 mm lift stroke and 13-second rise time make it suitable for assembly workstations, production lines, and material handling areas with demanding duty cycles. It features a 2-button standard control unit and an external power pack with a 3 m cable, powered by a 400V three-phase supply at 0.95 kW (S3). CE certified to EN 1570-1.

The CCB 1000B is a low-profile scissor lift table with a 1000 kg capacity, a 1500×1000 mm platform, and a minimum height of just 85 mm, designed for floor-level integration in production lines or material handling areas with limited vertical clearance. The 715 mm lift stroke brings the load platform to an ergonomic working height in 13 seconds, powered by a 400V three-phase motor unit rated at 0.95 kW (S3) with an external power pack featuring a plastic cover and 3 m cable. The standard 2-button control unit provides straightforward operator control. The product is CE certified to EN 1570-1.

The CCB 1000 is a low-profile scissor lift table with a minimum height of 85 mm, designed for integration into production lines where vertical clearance is restricted. With a 1,000 kg load capacity, a 715 mm lift stroke and a 1,500×800 mm platform surface, it supports ergonomic workstation adjustment and uninterrupted material flow in lean manufacturing environments. The electro-hydraulic drive (0.95 kW, three-phase 400V supply) delivers a 13-second lift cycle, controlled via a standard 2-button unit with an external power pack. CE certified to EN 1570-1.

The TUB 600H is a low-profile scissor lift table rated at 600 kg, with a minimum height of just 85 mm and a lift stroke of 965 mm, designed for integration into production lines where floor-level installation clearance is limited. The 1450 × 900 mm platform reaches full height in 19 seconds, powered by a three-phase 400V / 0.95 kW (S3) motor unit with a 3 m external power pack. Operation is handled via a standard 2-button control unit for straightforward operator use. CE certified to EN 1570-1.

The TUB 600 is a low-profile scissor lift table with a 600 kg capacity, 85 mm minimum height, and 715 mm lift stroke, designed for integration in production environments with limited vertical clearance. The 1450×900 mm platform and 13-second lift cycle support efficient material handling workflows. The unit runs on 400V three-phase power with an external power pack (L=3m) and a standard 2-button control unit; CE certified to EN 1570-1.

The TUL 2000 is a low-profile scissor lift table with a 2000 kg load capacity, 100 mm minimum height, and 820 mm lift stroke, designed for industrial environments where vertical clearance is limited and heavy loads must be handled efficiently. The 1350 × 1180 mm platform reaches working height in 24 seconds via an external power pack with a 3 m cable, powered by a three-phase 400V supply and operated through a standard 2-button control unit. CE certified to EN 1570-1, ensuring compliance with European safety standards for lift tables.
