Rounded roller track for Green Frame gravity flow systems, available in a standard length of 4000 mm (custom lengths on request). Designed to achieve the required curve radius within gravity roller lines, it ensures smooth directional transitions in layouts with non-linear material flow paths. An integrative component of the modular Green Frame system for lean manufacturing and logistics material flow management.

The Roller Track HD is a gravity roller track designed for free-flow systems where higher mechanical strength is required compared to the standard version. Standard length 4000 mm; custom lengths available on request. Suited for production and logistics environments where load conditions demand a heavy-duty roller track solution.

Swivelling wheel with brake for loads up to 30 kg, made of elastic rubber with low rolling friction, suitable for light-duty trolleys and Green Frame structures. Available in both unthreaded and M8 thread versions to fit different mounting configurations.

The High Load Wheel is an industrial castor with a 160 mm diameter and a load capacity of up to 400 kg, designed for Green Frame structures operating under heavy loads. Available in fixed and swivel-with-brake configurations, it features ball bearings and a polyurethane tread for smooth rolling and floor protection. Suited for trolleys, workstations, and lean material-handling systems requiring reliable performance under continuous load.

Levelling foot with central hole, M12 thread and 80 mm length, designed for Green Frame modular structures. The 60 mm base diameter provides stable support on industrial floors, while the through-hole allows floor anchoring where required. Available in size combinations to suit different modular configurations.

Steel Foot is a steel-and-rubber levelling foot for Green Frame profile systems, available in two diameters (30 and 45 mm) with M12 thread and 80 mm length. The fixing mechanism relies on the rubber section expanding as the screw is tightened, ensuring a secure connection to the frame structure. Suitable for lean workstations and modular tubular profile assemblies.

The plastic leveling foot is designed to support and adjust the height of modular Green Frame structures in industrial and logistics environments. Available in two diameters (30 and 50 mm) and two lengths (80 and 120 mm), it suits different load and clearance requirements. Thread size can be selected between M8 and M12 depending on the profile or connecting element used.

Central-hole wheels for Green Frame structures, available in swivelling or swivelling-with-brake versions and in 100 or 125 mm diameters. The polyamide or elastic rubber wheel, combined with ball bearings featuring protective caps, ensures smooth rolling and durability under continuous use. Maximum load capacity 150 kg per wheel, suitable for trolleys and modular structures in industrial and logistics environments.

The Roller Track Double Wheel is a gravity roller track from the Green Frame line, designed for the conveying and sliding of bins and trays in lean manufacturing systems. The double-wheel design ensures stable load guidance along the track. Available in Standard and ESD versions (for electrostatic discharge-sensitive environments), in a standard length of 4000 mm (custom lengths on request), in grey.

The Roller Track with Edge is a gravity roller rail from the Green Frame system, available in Standard and ESD versions for electrostatic-sensitive environments. The integrated edge ensures safe lateral containment and guidance of sliding loads, making it suitable for flow rack shelving, assembly lines and lean workstations. Available in grey, standard lenth 4000mm but and custom lenth to fit modular configurations of varying depth.

The Roller Track is a gravity roller rail designed for integration within Green Frame profile systems. Available in Standard and ESD versions — the latter suited for electrostatic-sensitive environments — it accommodates multiple layout configurations with a standard length of 4000 mm and custom lengths on request. Color options (red, black, grey) enable visual flow coding in line with lean visual management principles.

Tubular protection for the Green Frame GF-N system (Ø 28 mm), available in 2000 mm length. Ensures compatibility between GF-N (28 mm) tubes and G-series (43 mm) connectors, extending the configuration options of lean structures. Available in five colors (red, white, blue, yellow, green) to support visual management on the shop floor.

The Label Holder for Green Frame is an accessory for the GF-N Ø 28 mm tubular system, available in Base and Frontal versions with a standard length of 1550 mm (custom lengths on request). It allows the Green Frame to be fixed to walls or panels, integrating visual management directly onto the structure. Suitable for workstations and facilities requiring stable, organised identification of storage or processing points.

The Composite Material Panel is a configured polypropylene panel available in 5, 10, and 12 mm thicknesses, with a wide selection of lengths and widths to suit various visual management and lean manufacturing applications. Its low weight (81 g/m²) makes it easy to integrate into aluminum profile systems, delivering a clean and professional finish. Designed for quick installation without additional machining, it is suitable for workstations, modular frames, and industrial assembly stations.

Wheels with fixing plate designed for the Green Frame system, available in fixed, swivelling, and swivelling with brake configurations. Wheel diameter 100 or 125 mm, in polyamide or elastic rubber with ball bearings, supporting loads up to 150 kg. The fixing plate allows secure mounting on walls or flat surfaces with a maximum thickness of 2 mm, providing controlled mobility and stability in industrial environments.

The WP 65 is an electric work positioner with a maximum capacity of 65 kg at 400 mm from the mast, available in steel and stainless steel versions. It offers three stroke options (965, 1200 and 1600 mm), a lifting speed of 120 mm/s and a range of 150–250 cycles powered by 24 V - 9 Ah AGM batteries. The choice of leg configurations (standard, angle or central) combined with Ø 75 swivelling front wheels and Ø 125 braked rear wheels ensures stability and maneuverability on the production floor. Operation is managed via the ergonomic WPR-R1 handle with integrated remote control.

Dibond S/Silver SP. 3mm is a configured composite panel available in a wide range of formats, with lengths up to 3050 mm and widths up to 1500 mm. Suitable for visual management applications, industrial signage, and workstation setup in lean manufacturing environments. The silver finish and 3 mm thickness provide structural rigidity while keeping the overall panel weight low. Available in predefined dimensional variants to simplify integration into existing layouts.

WP 55 is a mobile work positioner with a maximum load capacity of 55 kg, available in steel or stainless steel versions, suitable for industrial, food processing, pharmaceutical and logistics environments. Lifting speed is 120 mm/s with three selectable stroke options (965, 1200 or 1600 mm) and a total height of 1530 mm. Powered by 2 AGM 24V-9Ah batteries with an external 230V charger, it delivers 150–250 cycles per charge; rear wheels Ø 125 with brake and front swivel wheels Ø 75 ensure maneuverability and stability. The leg configuration (standard, angle or central) allows adaptation to different load types and workstation layouts.

The Pudu T600 Underride is an AMR robot for heavy industrial logistics, with a payload capacity of up to 600 kg and compact dimensions of 845×500×255 mm for a self-weight of 94 kg. LiDAR SLAM navigation ensures autonomous and reliable path planning, with adjustable speed between 0.2 and 1.2 m/s and capability to overcome height differences up to 10 mm and grooves up to 35 mm in width. The 30 Ah battery ensures 12 hours of autonomy when unloaded and recharges from 0% to 90% in just 2 hours, with the option of recharging via dedicated station, cable or manual battery swap. The underride configuration allows direct coupling under trolleys and shelves, optimizing internal material handling flows without significant infrastructure modifications.

The Pudu T600 is an AMR robot for industrial logistics with payload capacity up to 600 kg, designed for production environments requiring autonomous handling of heavy loads. Hybrid navigation VSLAM + LiDAR SLAM ensures reliable paths in dynamic environments, with adjustable speed between 0.2 and 1.2 m/s and minimum passage space of 700 mm. The 30 Ah battery ensures autonomy of 12 hours unloaded and recharges up to 90% in 2 hours, with three modes available: recharging station, wired recharging, and manual replacement. The 10.1 inch LCD screen facilitates operational monitoring directly on the unit.
