The GFJ-D49 free swivel external connector is designed for the Green Frame GF-N modular system with Ø 28 mm tubes, enabling angular joints continuously adjustable from 0° to 180° without fixed preset positions. Die-cast aluminium construction (114 g) provides structural rigidity while keeping weight low, making it suitable for lean workstations, trolleys and industrial racking. The external joint type allows a visible tube-to-tube connection while retaining full flexibility for future reconfiguration.

The Long 45° Bracket (GFJ-D45) is a die-cast aluminium angular connector designed for the Green Frame GF-G modular system with Ø 43 mm tubes. Weighing 156 g, it provides reliable structural reinforcement at 45° joints in industrial frames, workstations and visual management systems. The 'long' version offers an extended contact surface compared to the standard bracket, increasing joint rigidity.

The Bridge Connector N/G (GFJ-D43) joins Ø 28 mm tubes (GF-N series) with Ø 43 mm tubes (GF-G series), enabling hybrid structures within lean manufacturing workstations and industrial assembly areas. Die-cast aluminium construction provides structural rigidity at a unit weight of 104 g. Fully compatible with the modular Green Frame ecosystem for racks, carts, and visual management systems.

The GFJ-D40 10° internal connector is designed to join tubes in the Green Frame system for both the GF-N (Ø 28 mm) and GF-G (Ø 43 mm) series, enabling angled internal joints at 10°. Compatible with both tube diameters, it integrates into modular structures for lean workstations, racking, and industrial visual management applications.

The Internal 45° Connector N (GFJ-D37) is an angled joint for the Green Frame GF-N modular system with Ø 28 mm tubing, designed to create internal 45° connections between structural profiles. Made from die-cast aluminium (55 g), it combines strength and low weight, making it suitable for lean manufacturing environments and industrial workstation assemblies.

The 45° Outer Connector N (GFJ-D34) is designed for the Green Frame GF-N modular system with Ø 28 mm tubes, enabling 45° angled joints in outer configuration. Made from die-cast aluminium (61 g), it provides structural rigidity while keeping the overall weight of lean structures low. Suitable for assembling workstations, trolleys and racking systems in manufacturing and logistics environments.

The GFJ-D32 90° L External Connector is designed for the Green Frame GF-N system with Ø 28 mm profiles. The extended version ensures full compatibility with the standard 90° connector, expanding structural configuration options. Weighing 155 g, it integrates into modular constructions typical of lean workstations, racking systems, and assembly lines.

The GFJ-D30 external swivel connector enables 0° to 180° angular joints between tubes in the Green Frame GF-N Ø 28 mm modular system, supporting non-orthogonal lean structure configurations. Die-cast aluminium construction (114 g) provides structural rigidity while keeping overall assembly weight low. Suitable for workstations, trolleys, and industrial racking requiring variable-angle connections.

The GFJ-D28 double 90° external connector, made of die-cast aluminium, is designed to join Green Frame GF-N Ø 28 mm profiles at a right angle, with declared compatibility with the GF-G Ø 43 mm system as well. The double configuration allows connection of two adjacent profiles in a single node, providing structural rigidity to the assembly. Weighing 127 g, it integrates into modular Green Frame structures for workstations, racking, and industrial visual management applications.

The External 90° Angle Connector N (GFJ-D26) is a joint for the Green Frame GF-N modular system with Ø 28 mm tubes, designed to create right-angle connections between profiles. The extended version ensures full compatibility with the standard 90° connector in the same product line. Weighing 96 g, it integrates seamlessly into workstation setups, shelving units, and lean assembly structures.

The GFJ-D24 is a 90° rotatable inner joint in die-cast aluminium, designed for the Green Frame GF-N modular system with Ø 28 mm profiles. The inner-type design provides a cleaner aesthetic finish compared to external connectors, keeping the structure neat and visually uncluttered. Compatible with GF-G 43 mm profiles, it offers assembly flexibility for lean structures and industrial workstations. Weight: 47 g.

The Cross Stitches Connector GFJ-D02 is a die-cast aluminium cross joint (97 g) designed for the Green Frame GF-N Ø 28 mm tubular system. It enables cross-connections between tubes in the assembly of modular structures such as workstations, carts, and visual management systems. This version offers extended compatibility with the 90° connector, broadening the range of possible configurations.

The Linear Connector N (GFJ-D01) is a 63 g die-cast aluminium joint designed for the Green Frame GF-N modular system with Ø 28 mm tubes. It provides axial connection between system tubes, with a radial load capacity of up to 450 N and a thrust capacity of up to 750 N. Suitable for assembling lean manufacturing structures, ergonomic workstations, and lightweight industrial racking.

Inner 90° angle connector for the GF-N Ø 28 mm Green Frame modular system, also compatible with 43 mm GF-G profiles. The integrated alignment groove ensures accurate positioning when rotating the frame, delivering both structural precision and a clean visual result. Weight: 122 g. Suitable for lean workstations, ergonomic assembly structures, and industrial visual management applications.

The Free Connector (Side M) N – GFJ-C79 is a side joint for the Green Frame GF-N Ø 28 mm modular tube system, designed to connect structural elements with a lateral orientation. Weighing 84 g, it integrates into the Green Frame ecosystem for building workstations, racks, and lean structures. An extended version (139 g) is also available for applications requiring compatibility with 90° connectors.

The Quick Clamper (GFJ-C20) is a moving component for the Green Frame modular system, designed for Ø 28 mm GF-N tubes and engineered to enable straightforward Kanban card integration at workstations. Weighing just 80 g, it adds minimal load to the structure while supporting lean visual management applications. Suitable for production environments where on-line information handling needs to remain practical and efficient.

The Hinge Connector Stopper (GFJ-B95) is a locking element for the Green Frame modular system, designed to fix hinge connectors in pipe-and-joint structures. Weighing 13 g, it integrates into the system's movable joints to arrest rotation and maintain the assembled configuration in a set position. Suitable for lean workstations and visual management structures where adjustable components need to be locked in place.

The GFJ-B89 is a 45° point connector in die-cast aluminium (43 g), designed for the Green Frame GF-S Ø 19 mm modular system with extended compatibility for GF-N (Ø 28 mm) and GF-G (Ø 43 mm) profiles. It enables secure profile fixing at 45° inclination in lean workstation assemblies, flow racks, and visual management structures. Cross-series compatibility makes it a practical choice for mixed-diameter configurations within the same installation.

The Rotary Connector with Bearing (GFJ-B83) is a bearing-equipped connector for the Green Frame GF-S Ø 19 mm system, designed for joints requiring rotary, sliding or hinge movement within the structure. Weighing 115 g, it includes the connection cable for the control unit. Suitable for visual management applications and lean manufacturing workstations where component orientation flexibility is required.

The S-Type Rotary Cross Connector (GFJ-B77) is designed for the Green Frame GF-S modular system with Ø 19 mm profiles, enabling cross-joining of tubes at adjustable angles. Made from aluminium and weighing 38 g, it integrates into lean workstation structures, shelving and visual management systems. Its rotary function allows connections at any inclination, distinguishing it from the fixed cross connector GFJ-B55.
