Boards Holder G is a mobile element for the Green Frame GF-G modular system (Ø 43 mm), available in flush and lowered versions to suit different installation requirements. Made from anodized aluminum, it combines lightness and durability: model GFJ-A33 weighs 21 g, GFJ-A34 weighs 19 g. It enables boards and panels to be mounted directly onto Green Frame profiles, supporting visual management applications in industrial environments.

Panel fixing accessory compatible with the GF-N Ø 28 mm Green Frame tubular system. Available in flush or recessed version, it allows panels to be secured to GF-N structures to suit different mounting requirements in lean workstations and visual management applications. Made from polypropylene and weighing just 4 g, it adds minimal weight to the overall assembly.

The SFK-K31J hook is an accessory for the Green Frame GF-N modular system with Ø 28 mm tube, designed for Type J configuration to support and connect components within the structure. The PA body keeps weight minimal at 3 g, while the stainless steel hook provides mechanical strength and corrosion resistance in industrial environments. Suitable for lean workstations, assembly stations, and visual management applications.

The SFK-809 kit enables the installation of L40 rollers on C10 connectors within the Green Frame GF-N Ø 28 mm system, adding moving parts to lean manufacturing structures. Each roller supports a load capacity of 150 N and requires a tightening torque of 6.0 N·m for correct assembly. Steel bearings combined with extruded aluminium spacers ensure durability and consistent rolling performance. Total kit weight: 69 g.

The Linear Roller GFW-645 is an accessory for the Green Frame GF-N Ø 28 mm system, designed to fix rollers onto plates with a maximum thickness of 2 mm. Suitable for irregular surfaces, it is used in the assembly of roller tracks and supermarket racks. Weighing just 7.9 g, it keeps the overall structure lightweight without affecting system performance.

The Rotation Kit N (GFW-557) consists of 2 pieces designed for the Green Frame GF-N Ø 28 mm modular system, enabling rotational movement within lean assembly structures. With a total weight of 700 g, it integrates into the Moving Parts family to create pivot and rotation points on carts, dynamic racks, and workstations. Compatible with GF-N system Ø 28 mm tubular profiles.

PA end cap compatible with GFF-M05 connector, supplied in a 2-piece kit for the Green Frame system on Ø 28 mm tubes. Each kit includes 2 caps and 2 cross recessed countersunk head self-tapping screws (3.5 x 12 mm) for a complete and clean installation. Total kit weight: 16 g. Designed to close open tube ends on lean assembly structures and industrial workstations.

Stop roller for the Green Frame GF-N Ø 28 mm modular system, designed to fix rollers onto plates with a maximum thickness of 2 mm. Unlike standard rollers, it provides no rotation, acting as a fixed stopping element within flow and handling structures. Weighing just 18 g, it integrates seamlessly into lean conveying systems without adding significant load to the assembly.

The GFW-294 Steel Stopper Element is a structural component of the Green Frame GF-N series, designed for Ø 28 mm tubes. Weighing 34 g, it integrates into moving part arrest systems within lean assembly structures, dynamic racking, and industrial workstations. It provides precise movement blocking along GF-N tubular profiles.

The C6 N/G connector (GFQ-017) is a 50 mm anodized aluminium accessory designed to join profiles within the Green Frame modular system, compatible with both GF-N Ø 28 mm and GF-G Ø 43 mm series. At just 18 g, it adds minimal weight to mobile structures and lean workstation assemblies. Its dual-diameter compatibility makes it a practical choice for mixed-profile configurations.

The GFQ-016 Door Lock is an accessory designed for the Green Frame GF-N modular system with Ø 28 mm tubes. The mounting part is made of extruded aluminium, while the body is stainless steel, for a total weight of 123 g. It provides stable door fastening within industrial structures and lean workstations, preserving the visual and operational functionality of the system.

The GFQ-007 Frame Locking Magnet Kit is a magnetic locking accessory designed for Green Frame GF-N systems with Ø 28 mm profiles. The kit combines a ferrite magnet housed in a stainless steel casing with an extruded aluminium mounting part, for a total weight of 195 g. It enables fast, repeatable frame locking in visual management systems and lean workstations without the need for tools.

The Frame Locking Magnet with Switch N (GFQ-004) is a magnetic locking accessory designed for Green Frame GF-N Ø 28 mm tubular systems. It features an integrated switch to enable or disable the magnetic holding function, ensuring controlled and repeatable frame fixation at lean workstations. Weighing 195 g, it mounts directly onto the tubular structure without additional tooling.

The Panel Locking Magnet Kit N (GFQ-003) is a magnetic catch kit designed for panel door locking on Green Frame GF-N systems with Ø 28 mm tubes. The mounting part is made from extruded aluminium, the housing from stainless steel, and the magnet from ferrite, with a total weight of 130 g. The kit includes the hardware required for direct installation on the GF-N profile. Suitable for lean workstations and visual management systems requiring panel openings with magnetic snap closure.

The Panel Locking Magnet + Switch N (GFQ-000) is an accessory for the Green Frame GF-N Ø 28 mm system, designed for magnetic locking of panels in lean workstations and visual management applications. It incorporates a switch that enables panel position detection, providing reliable open/closed status monitoring. Weighing 143 g, it integrates directly into the GF-N structure without requiring additional tooling.

GFN-E31 is an M12 threaded steel compass designed to connect GFF-019 levelling feet to Green Frame GF-N Ø 28 mm profiles. Weighing just 14 g, it integrates into the modular Green Frame system to enable height adjustment of industrial structures and workstations. A dedicated replacement or completion component for the GF-N ecosystem exclusively.

The Foot Connector M6 S (GFN-E07) is a levelling foot connector designed for the Green Frame modular system, manufactured in polyamide for a minimal weight of just 4 g. It ensures the connection between the tubular structure and adjustable feet in lean manufacturing and industrial workstation assembly applications. The M6 thread makes it suitable for compact configurations within the Green Frame system.

ABS connector with M8 threading, designed to attach levelling feet and wheels to the GF-N Ø 28 mm tubular profiles of the Green Frame system. It provides the mechanical interface between the frame profile and levelling or mobility elements, maintaining assembly rigidity. At just 12 g, it keeps the overall weight of lean structures to a minimum.

The Wheel Connector with Plate N (GFN-C10) is a wheel connector designed for the Green Frame modular system, enabling the integration of wheels and levelling feet on lean manufacturing structures. Weighing just 64 g, it offers a load capacity of 750 N — twice that of the standard Hinge Connector Stopper. Suitable for trolleys, workstations, and modular frames requiring mobility or height adjustment.

Black NBR rubber inner sole designed for the levelling feet of the Green Frame GF-N Ø 28 mm series. At just 16 g, its plug-in and stackable design enables tidy storage and easy handling. Provides grip and floor protection in lean structures built with 28 mm tubing.
